Shelving.com
Gravity Conveyors — Roller & Wheel Bed Systems
Got a lot of product that needs to move quickly? Our roller- and wheel-bed gravity conveyors transport packages of nearly any size down the line for further handling—no power required.
Fully compatible with our gravity flow racks, gravity conveyors are configured to your layout, load type, and throughput goals—not sold off the shelf.
Gravity Conveyor Features
A series of rollers and wheels lets you move packages and products of nearly any size quickly and easily—using nothing but gravity.
- Spring-loaded for easy installation
- Several options to mount to rack or floor
- Corrosion-resistant steel construction
- Lightweight aluminum option available
- Light, standard, and heavy-duty options
- Available in custom, to-the-inch sizes
- Backed by a 2-year warranty
Configurations
These variations work with your space to get you a system that fits your unique specifications.
- Gravity Conveyor with Gate: lets personnel cross the conveyor without climbing over or under it.
- Gravity Conveyor with Curve: a curved section transports cartons around corners to the next process. Available in 45° and 90° angles.
Tech Specs
Choose roller or wheel bed conveyor in steel or aluminum, sized to your product and run length. Final capacities are confirmed during configuration.
- Roller Conveyor: lengths 12" to 144" in ½" increments; standard widths of 12", 18", 24", 30", and 36"; roller centers of 3", 4½", and 6".
- Roller Conveyor construction: 1⅜" diameter galvanized steel rollers in a 12-ga. steel C-channel frame, or 1⅜" aluminum rollers in an extruded aluminum frame.
- Wheel Bed Conveyor: lengths 12" to 144" in ½" increments; standard widths of 12", 15", 18", and 24"; wheels spaced on 3" centers.
- Wheel Bed construction: 1-15/16" zinc-plated steel wheels (or aluminum) in a galvanized steel or extruded aluminum channel frame.
Accessories
Add accessories to control flow, protect loads, and keep operators safe along the line.
Package Stop
Steel protection to handle the toughest loading conditions.
Roller Stop
Supports loads while taking product from the end of the conveyor.
Fixed Angle End Stop
Mounts to the end of a conveyor to stop flow. Available in all standard conveyor widths.
Adjustable Guard Rail
Available for straight or curved sections, on one or both sides.
Fixed Angle Guard Rail
Can be toed in or out, for straight or curved sections, on one or both sides.
Real-World Example
Capital Candy Co., a full-fledged grocery and convenience-store wholesaler, was running out of space as manufacturers introduced hundreds of new products. A collection of UNEX carton flow and gravity solutions helped them increase productivity and keep pace with surging inventory.
See Gravity Conveyors in Action
Frequently Asked Questions About Gravity Conveyors
Shelving.com helps warehouse and distribution teams compare roller and wheel bed gravity conveyors, plan curves and gates, and gather the details needed before requesting a quote.
What is a gravity conveyor?
+
A gravity conveyor uses a series of rollers or wheels—and a slight decline or manual push—to move packages and products down the line with no power required. It's a simple, durable way to transport loads of nearly any size for further handling.
What's the difference between roller and wheel bed gravity conveyor?
+
Roller conveyor uses 1⅜" rollers and suits heavier or larger cartons and longer runs. Wheel bed conveyor uses closely spaced wheels and handles lighter or smaller items with low rolling resistance. Both are available in steel or aluminum.
Can gravity conveyor turn corners or let people cross it?
+
Yes. Curved sections in 45° and 90° angles route product around corners, and a gate configuration lets personnel cross the conveyor without climbing over or under it.
Does gravity conveyor work with gravity flow racks?
+
Yes. Our gravity conveyors are fully compatible with our gravity flow racks, creating smooth, fast product transport across any size warehouse or storage facility.
What sizes and capacities are available?
+
Conveyors come in lengths from 12" to 144" in ½" increments, multiple standard widths, and light, standard, and heavy-duty options. Custom, to-the-inch sizes are available, and final capacities are confirmed during configuration.
How do I get a quote for a gravity conveyor system?
+
Share your product type and weight, run length, layout (including any curves or crossings), and how the conveyor connects to your racks or workstations. We'll recommend roller or wheel bed, the right material, and accessories, then quote the system.
